JEE Main 2026 — Jan 24, Shift 2 — Physics solution

JEE Main2026Jan 24, Shift 2Physics

A regular hexagon is formed by six wires each of resistance $R$ $Ω$ and the corners are joined to centre by wires of same resistance. If the current enters at one corner and leaves at the opposite corner, the equivalent resistance of the hexagon between the two opposite corners will be

A
$\frac{4}{5} R$
B
$\frac{5}{8} R$
C
$\frac{3}{4} R$
D
$\frac{3}{5} R$

Solution

$R_{e q} = \frac{2 R \cdot ( 4 R /3 )}{2 R + 4 R /3} = \frac{8 R ^{2} /3}{10 R /3} = \frac{4 R}{5}$ .

$∴ R_{e q} = \frac{4 R}{5}$ .
